KL Kompakt 30
| Nominal flow (performance) Q | 30 l / s |
| DN | 250 mm |
| Tank capacity | 1 |
| Sludge tank volume | 4 m3 |
| External length L | 3300 mm |
| External Width W | 2200 mm |
| Height H | 1500 mm |
| Ceiling slub thickness | 140 |
| Base height of intake pipe from bottom Hi | 1200 mm |
| Base height of drain pipe from bottom Ho | 1080 mm |
| Heaviest weighing piece | 8 t |
| Výstupná hodnota vyčistenej vody z ORL [mg] | do 0,5 mg/l NEL |
ORL
Oil-water separator
ORL KL 250 4sII
Oil-water separator ORL KL 235/3
Schmidt hammer shows 45
Inlet rectifier from the sludge tank
First tank is sludge tank ORL 250 4 sII
Reservoir sludge tank
Sludge tank inflow
Sludge tank ORL 250 4 sII
Sludge tank & coatings
Sorption filter is too dirty
Separator KLk5
Loading 4 units ORL KLK
ORL KL in groundwater Beladice - Tekovské Nemce
The plastic separator
Inside the plastic separator
